Yamaha XP500 - Page 244

4 - 46
CHAS
1
3
4
5
6
7
10
10
8
8
12
9
New
LS
2
2
T
R
.
.
27 Nm (2.7 m
•
kg, 19 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
11
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
11
Order Job/Part Q’ty Remarks
11 Front brake caliper bracket bolt 2 2
Refer to “ASSEMBLING AND INSTALL-
ING THE FRONT BRAKE CALIPER”.
12 Brake caliper bracket 1
For installation, reverse the removal pro-
cedure.
FRONT AND REAR BRAKES
