2 - 31
SPEC
COOLANT FLOW DIAGRAMS
EAS00035
COOLANT FLOW DIAGRAMS
1
Coolant reservoir
2
Thermostat
3
Radiator
4
Water pump
5
Radiator fan
6
Radiator cap
7
Fast idle plunger
1
2
3
5
6
2
3
6
4
7
