LUBRICATION POINTS AND LUBRICANT TYPES
LUBRICATION POINTS AND LUBRICANT TYPES
ENGINE LUBRICATION POINTS AND LUBRICANT TYPES
Lubrication point Lubricant
Oil seal lips
LS
O-rings
LS
Bearing and bushes
E
Crankshaft pins
E
Piston surfaces
E
Piston pins and connecting rod small end
E
Balancer surface
E
Connecting rod big end thrust surface
E
Connecting rod bolts and nuts
M
Crankshaft thrust surface
E
Crankshaft journals
E
Camshaft lobs
M
Camshaft journals
M
Camshaft cap
M
Valve stems (intake and exhaust)
M
Valve stem ends (intake and exhaust)
E
Cylinder head nut
E
Water pump impeller shaft
M
Oil pump shaft
E
Oil pump rotors (inner and outer)
E
Oil pump O-ring
LS
Oil cooler union bolt
E
O-ring (fuel injector assembly) Silicone oil
Starter clutch idle gear inner surface
E
Starter clutch
E
Main axle thrust surface or
Main and drive axle serration or
Drive axle spline or
Chain drive case and taper bearing
LS
Bearing (chain drive case) Chain drive oil
Primary sheave spacer Shell BT grease 3
®
Primary sheave nut Shell BT grease 3
®
E
LS
E
LS
E
LS
