8 - 3
– +
ELEC
1 ECU (ABS) (XP500A)
2 Fail-safe relay (XP500A)
3 Main switch/immobilizer unit
4 Intake air pressure sensor
5 Coolant temperature sensor
6 ABS motor fuse
7 Fuel pump
8 Rear wheel sensor (XP500A)
9 O
2
sensor
0 Hydraulic unit (XP500A)
A Front wheel sensor (XP500A)
B Intake air temperature sensor
C ECU (engine)
3
1
2
4
5
6
7
8
9
0
A
B
C
ELECTRICAL COMPONENTS
