17
3. COMPONENT NAMES AND FUNCTIONS
Plumbing System
Solenoid Exhaust Valve
Solenoid Drain Valve
Pressure Gauge
Safety
Valve
Silencer
Drain Bottle
Heater 1
Drain Valve
Heater 2
Sensor 1
Sensor 2
Chamber
