Table B.3 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
−
Model CIMR-Jo
− 2A0001 2A0002 2A0004 2A0006 2A0010
o2-04 Drive Model Selection Hex 60 61 62 63 65
C6-01 Normal/Heavy Duty
− HD ND HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1 0 1
− Motor rated power kW 0.1 0.18 0.25 0.37 0.55 0.75 1.1 1.1 1.5 2.2
C6-02 Carrier frequency − 4 7 4 7 4 7 4 7 3 7
E2-01 Motor rated current A 0.60 1.10 1.10 1.90 1.90 3.30 3.30 4.90 6.20 8.50
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90 2.90 2.50 2.50 2.60 2.60 2.90
E2-03 Motor no-load current A 0.40 0.80 0.80 1.20 1.20 1.80 1.80 2.30 2.80 3.00
E2-05
Motor line-to-line
resistance
Ω
35.98 20.56 20.56 9.84 9.842 5.156 5.156 3.577 1.997 1.601
−
Momentary power loss
ride-through time
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
−
Momentary power loss
Baseblock time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
No. Description Unit Default Settings
−
Model CIMR-Jo
− 2A0012 2A0020
o2-04 Drive Model Selection Hex 66 68
C6-01 Normal/Heavy Duty −
HD ND HD ND
0 1 0 1
− Motor rated power kW 2.2 3.0 4.0 5.5
C6-02 Carrier frequency − 3 7 3 7
E2-01 Motor rated current A 8.50 11.40 14.0 19.60
E2-02 Motor rated slip Hz 2.90 2.70 2.73 1.50
E2-03 Motor no-load current A 3.00 3.70 4.50 5.10
E2-05 Motor line-to-line resistance Ω 1.601 1.034 0.771 0.399
−
Momentary power loss ride-
through time
s 0.5 0.5 1 1
−
Momentary power loss Baseblock
time
s 0.5 0.5 0.6 0.7
B.3 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA ELECTRIC TOEP C710606 26B YASKAWA AC Drive – J1000 Quick Start Guide
235
B
Parameter List
