3.4 Terminal Block Configuration
The figures in this section provide illustrations of the main circuit terminal block
configurations of the different drive sizes.
Models:
CIMR-JBA0006, 0010
CIMR-J2A0010, 0012, 0020
CIMR-J4A0001, 0002, 0004, 0005, 0007,
0009, 0011
Models:
CIMR-JBA0001, 0002, 0003
CIMR-J2A0001, 0002, 0004, 0006
Figure 3.5 Main Circuit Terminal Block Configurations
3.4 Terminal Block Configuration
YASKAWA ELECTRIC TOEP C710606 26B YASKAWA AC Drive – J1000 Quick Start Guide
43
3
Electrical Installation
