3.3 Keypad Operation
468 YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING
Figure 3.14 How to Change the Parameter Setting
Continue to change parameters or push and hold to go back to the frequency reference screen.
◆ Save a Backup of Parameters
Show the frequency reference screen.
Note:
Push and hold to return to the frequency reference screen from any screen.
Use these steps to save a backup of the drive parameters to the keypad.
Backups of the parameter settings can save time when you set parameters after you replace a drive. When you set up
more than one drive, you can copy the parameter settings from a drive that completed a test run to the other drives.
Note:
• Stop the motor before you back up parameters.
• While the drive makes a backup, it will not accept Run commands.
• Set o3-02 = 0 [Copy Allowed Selection = Disabled] to protect the parameters saved in the keypad.
Figure 3.15 How to Save Backed-up Parameters
To Next Page
