2.8 H: Terminal Function Selection
332 YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING
■ 6A: Data Logger Error
Setting Value Function Description
6 A Data Logger Error
The terminal activates when the drive detects a LoG [Com Error / Abnormal SD card].
■ 90 to 92: DWEZ Digital Output 1 to 3
Setting Value Function Description
90 - 92 DWEZ Digital Output 1 to 3
Sets the DriveWorksEZ digital output. Refer to the DriveWorksEZ online manual for more information.
■ 100 to 192: Inverse output of 0 to 92
Setting Value Function Description
100 - 192 Inverse output of 0 to 92
Causes inverse output of the function for the selected MFDO. Uses the last two digits of 1xx to select which function to inversely
output.
For example, set H2-xx = 10E for the inverse output of E [Fault].
◆ H3: Analog Inputs
WARNING! Sudden Movement Hazard. Do test runs and examine the drive to make sure that the command references are correct.
If you set the command reference incorrectly, it can cause damage to the drive or serious injury or death.
Drives have two analog input terminals: terminals A1 and A2. Use H3 parameters to set the functions to these analog
input terminals and adjust signal levels.
Table 2.56shows the functions that you can set to analog input terminals. Use H3-02 and H3-10 [MFAI Function
Select] to set functions.
Table 2.56 Multi-Function Analog Input Terminal Settings
Setting
Value
Function Reference
0 Frequency Reference 337
1 Frequency Gain 337
2 Auxiliary Frequency Reference 1 338
3 Auxiliary Frequency Reference 2 338
4 Output Voltage Bias 338
5 Accel/Decel Time Gain 338
6 DC Injection Braking Current 339
7 Torque Detection Level 339
8 Stall Prevent Level during Run 339
9 Output Frequency Lower Limit 339
B PID Feedback 340
C PID Setpoint 340
D Frequency Bias 340
Setting
Value
Function Reference
E Motor Temperature (PTC Input) 340
F Through Mode 340
10 Forward Torque Limit 340
11 Reverse Torque Limit 342
12 Regenerative Torque Limit 342
13 Torque Reference / Torque Limit 342
14 Torque Compensation 342
15 General Torque Limit 342
16 PID DifferentialFdbk 342
1F Through Mode 342
30 DWEZ Analog Input 1 343
31 DWEZ Analog Input 2 343
Note:
All analog input scaling uses gain and bias for adjustment. Set the gain and bias values correctly.
