5-50
D. Drive Capacity Function (uA)
The Drive Capacity function allows the user to verify that the parameter data stored in the digital
operator are from the same capacity and voltage class as the drive being written too. The voltage
and the drive capacity whose parameters are stored in the digital operator are displayed on the
digital operator. When “uA” is selected and Data/Enter is pressed.The value that is displayed
indicates the voltage and drive capacity in kilowatts. This value can be compared to the drive
specification number on the drive data nameplate.
E. Software Number Display
The software number display allows the user to check the software revision number of the parameter
data stored in the digital operator. This value can be compared to the PRG number on the drive data
nameplate.
Display
Model
CIMR-V7*U MV
20.1 20P1 A001
20.2 20P2 A002
20.4 20P4 A003
20.7 20P7 A005
21.5 21P5 A008
22.2 22P2 A011
24.0 23P7 A017
25.5 25P5 A025
27.5 27P5 A033
40.2 40P2 B001
40.4 40P4 B002
40.7 40P7 B003
41.5 41P5 B005
42.2 42P2 —
43.7 43P7 B009
45.5 45P5 B015
47.5 47P5 B018
5.29 COPY FUNCTION
