A2-1
(table continued on next page)
Appendix 2. SPECIFICATIONS
See notes at end of table.
SECTION A.
Model No. Related Specifications
230V Class
Model CIMR-V7*U 20P1 20P2 20P4 20P7 21P5 22P2 23P7 25P5 27P5
MV A001 A002 A003 A005 A008 A011 A017 A025 A033
Max. applicable motor output
1/8 (0.1) 1/4 (0.2) 1/2 (0.4) 1 (0.7) 2 (1.5) 3 (2.2) 5 (3.7) 7.5 (5.5) 10 (7.5)
HP (kW) (1)
Drive capacity (kVA) 0.3 0.6 1.1 1.9 3.0 4.2 6.7 9.5 13
Rated Output Current (A) 0.8 1.6 3.0 5.0 8.0 11.0 17.5 25 33
Max. Output Voltage (V) 200 to 230V (proportional to input voltage)
Max. Output Frequency (Hz) 400 Hz (programmable)
Rated Input Voltage and
3-phase. 200 to 230 V, 50/60 Hz
Frequency
Allowable voltage fluctuation -15% to +10%
Allowable frequency fluctuation ±5%
Cooling Method
NEMA 1 self self self fan fan fan fan fan(2) fan(2)
(QTY) NEMA 4 self self self self fan fan fan N/A N/A
460V Class
Model CIMR-V7*U 40P2 40P4 40P7 41P5 42P2 43P7 45P5 47P5
MV - - B001 B002 B003 B005 — B009 B015 B018
Max. applicable motor
output HP (kW) (1)
- - 1/2 (0.2) 3/4 (0.4) 2 (0.7) 3 (1.5) 3 (2.2) 5 (3.7) 7.5 (5.5) 10 (7.5)
Drive capacity (kVA) - - 0.9 1.4 2.6 3.7 4.2 7 11 14
Rated Output Current (A) - - 1.2 1.8 3.4 4.8 5.5 8.6 14.8 18
Max. Output Voltage (V) 380 to 460V (proportional to input voltage)
Max. Output Frequency (Hz) 400 Hz (programmable)
Rated Input Voltage and
3-phase. 380 to 460 V, 50/60 Hz
Frequency
Allowable voltage fluctuation -15% to +10%
Allowable frequency fluctuation ±5%
Cooling Method
NEMA 1 - - self self self fan fan fan fan(2) fan(2)
(QTY) NEMA 4 - - self self self fan fan fan N/A N/A
SECTION B.
All Drives
Control method Sine wave PWM (V/f Control or Open Loop Vector)
Frequency control range 0.1 to 400 Hz
Frequency accuracy Digital command: ±0.01% (14 to 122°F, -10 to +50°C)
(temperature change) Analog command: ±0.5% (77°F ± 18°F, 25°C ± 10°C)
Open Loop Vector: ±0.2%
Speed Regulation
V/Hz Mode: ±0.5% – 1% with Slip Compensation
Digital Operator reference: 0.01 Hz (< 100Hz)
Frequency setting resolution 0.1 Hz (100Hz or more)
Analog reference: 0.06Hz/60Hz (1/1000)
Output frequency resolution 0.01 Hz
Overload capacity 150% of rated output current for 1 minute
0 to 10VDC (20kΩ), 4 to 20mA (250Ω), 0 to 20mA (250Ω) pulse train input,
Frequency Reference Signal
Digital Operator Pot
0.01 to 6000 sec.
Accel/Decel Time
(accel/decel time are independently programmed)
Short-term average deceleration torque (2)
0.2kW: 150%
0.75kW: 100%
Braking Torque
1.5kW: 50%
2.2kW or more: 20%
Continuous regenerative torque: Approx. 20% (150% with
optional braking resistor, braking transistor built-in)
V/f characteristics Custom V/f pattern
Table A2-1. Standard Specifications
Output
Characteristics
Power
Supply
Output
Characteristics
Control Characteristics
Power
Supply
Physical
Character-
istics
Physical
Character-
istics
