5-11
Example 3 - Sixteen preset ref
erences
Programming: n053 = 6, n054 = 7, n055 = 8 and n056 = 9
DIGITAL PRESET S7 S6 S5 S4
Selectable Reference
(2)
Open Open Open Open
n025 Open Open Open Closed
n026 Open Open Closed Open
n027 Open Open Closed Closed
n028 Open Closed Open Open
n029 Open Closed Open Closed
n030 Open Closed Closed Open
n031 Open Closed Closed Closed
n120 Closed Open Open Open
n121 Closed Open Open Closed
n122 Closed Open Closed Open
n123 Closed Open Closed Closed
n124 Closed Closed Open Open
n125 Closed Closed Open Closed
n126 Closed Closed Closed Open
n127 Closed Closed Closed Closed
Continued
Example 2 - Eight preset ref
erences
Programming: n054 = 6, n055 = 7 and n056 = 8
DIGITAL PRESET S7 S6 S5
Selectable Reference
(2)
Open Open Open
n025 Open Open Closed
n026 Open Closed Open
n027 Open Closed Closed
n028 Closed Open Open
n029 Closed Open Closed
n030 Closed Closed Open
n031 Closed Closed Closed
5.11 FREQUENCY REFERENCE SELECTION
Example 1 - Four preset references
Programming: n054 = 6 and n055 = 7
DIGITAL PRESET S6 S5
Selectable Reference
(2)
Open Open
n025 Open Closed
n026 Closed Open
n027 Closed Closed
(2)
The Selectable Reference is chosen from the
following list:
C. Jog Reference - See paragraph 5.12
REFERENCE SOURCE PROGRAMMING
Digital Operator Speed Pot n004 = 0
Digital Preset Reference parameter n024 n004 = 1
Analog Input Terminal FR n004 = 2, 3, or 4
Pulse Train Reference n004 = 5
Serial Communications n004 = 6
