n The system variable USER_PARTITION is a system variable organized as a data
structure.
n You can use the USER_PARTITION system variable to retrieve various information
and memory statistics on the user partition (overlay file system).
n The partition can be on the external Yaskawa SD card or on the internal memory.
n The memory is organized in blocks.
n A block has a constant, fixed size and a file always uses one or more blocks.
n A certain number of blocks are reserved in the Linux system for the root user. These
reserved blocks are only available for the root user and ensure his ability to act even
if the memory is occupied (e.g. for log outputs).
System variable Type - description
USER_PARTITION PARTITION_INFO - data structure
MEM_TOTAL ULINT - total memory of the partition in bytes (including reserved
blocks).
MEM_FREE ULINT - free, available memory in bytes (without reserved blocks).
MEM_USED ULINT - used memory in bytes (including reserved blocks).
MEM_USAGE ULINT - used memory in % (without reserved blocks).
n In iCube Engineer programs and program parts are treated as tasks.
n The Execution & Synchronization Manager (ESM) is responsible for coordinating and
processing the individual tasks.
n You can use the ESM_DATA system variable to retrieve information about the ESM's
task handling.
n ESM_DATA is a system variable organized as a data structure.
System variable Type - description
ESM_DATA ESM_DAT - data structure
ESM_COUNT USINT - number of ESM (one ESM per processor core).
ESM_INFOS ESM_INFO_ARRAY
[1] ... [2]
ESM_INFO - Information about the ESM [1 ... 2]
2
.
TASK_COUNT UINT - number of tasks that were configured for the ESM.
TICK_COUNT UDINT - always 0.
TICK_INTERVAL UDINT - always 0.
TASK_INFOS TASK_INFO_ARRAY
[1] ... [16] TASK_INFO - Information about the tasks [1 ... 16].
INTERVAL
1
LINT - time interval
n With cyclic tasks: Time interval in μs
n With acyclic tasks: 0
PRIORITY
1
INT - priority of the task
Partition
Task handling
iC9200 Series
Deployment
System variables and status information > System variables
HB700 | CPU | PMC921xEx | en | 23-06 116
