2.9 General data for iC9200 Series
Conformity and approval
Conformity
CE 2014/30/EU EMC directive
Approval
UL UL 61010-2-201 UL is in preparation
Others
RoHS 2011/65/EU Directive on the restriction of the use of certain haz-
ardous substances in electrical and electronic equipment
Protection of persons and device protection
Type of protection - IP20
Electrical isolation
to the field bus - electrically isolated
to the process level - electrically isolated
Insulation resistance EN 61010-2-201 -
Insulation voltage to reference earth
Inputs / outputs - AC / DC 50V, test voltage AC 500V
Protective measures - against short circuit
Environmental conditions to EN 61131-2
Climatic
Storage / transport EN 60068-2-14 -40…+85°C
Operation
Horizontal installation hanging EN 61131-2 0…+60°C
Horizontal installation lying EN 61131-2 0…+55°C
Vertical installation EN 61131-2 0…+40°C
Air humidity EN 60068-2-30 RH1 (without condensation, rel. humidity 10…95%)
Pollution EN 61131-2 Degree of pollution 2
Installation altitude max. - 2000m
Mechanical
Oscillation EN 60068-2-6 1g, 9...150Hz
Shock EN 60068-2-27 15g, 11ms
iC9200 Series
Basics and mounting
General data for iC9200 Series
HB700 | CPU | PMC921xEx | en | 23-06 41
