MotionSuite™ MP940 Machine Controller Hardware Manual Section 13: Dimensional Drawings and Cable Diagrams
64
Connector Specifications
Name Connector Name
# of
Pins
Connector Model
Controller Side Cable Side Manufacturer
Battery
Connector
BAT 2 DF3-2P-2DS Battery
BA000518
Connector
HIROSE
Serial Port
RS-232C
PORT1 14 10214-52A2JL Connector Unit
10114-3000VE
Shell
10314-52A0-008
3M
Serial Port
RS-422/485
PORT2 14 10214-52A2JL Connector Unit
10114-3000VE
Shell
10314-52A0-008
3M
Power Connector POWER 3 SL3.5/3/90F BL3.5/3F-AU Weidmuller
Mechatrolink
Connector
MECHATROLINK 4 DUSB-APA41-T11 DUSB-
I/O Connector I/O 50 10250-52A2JL Connector Unit
10150-3000VE
Shell
10350-52A0-008
3M
LED Connector LED 16 IMSA-9220B-16A
