MotionSuite™ MP940 Machine Controller Hardware Manual Section 13: Dimensional Drawings and Cable Diagrams
67
Mechatrolink Cables
Mechatrolink Cable
The internal cable connections between the MP940 and the I/O unit are shown below:
Figure 13.7: Mechatrolink Cable
46
8
46
21
1
2
3
4
Shell
1
2
3
4
Shell
Pin No.
Name
(NC)
*DATA
DATA
SH
Shield
Name
(NC)
*DATA
DATA
SH
Shield
Cable Model: JEPMC-W6000- 
