YASKAWA MotionSuite MP940

MotionSuite™ MP940 Machine Controller Hardware Manual Section 2: Startup
5
Section 2: Startup
Mounting Orientation
Mount the SGDH and MP940 in the appropriate direction for proper cooling, as shown
on the left below.
Correct Incorrect
Figure 2.1: Mounting Orientation
SGDH MP940
SGDH MP940
