1 Product Confirmation
1.2 Order Number Confirmation
1-2
157569-1CD
HW0485652
MPL100
1.2 Order Number Confirmation
Check that the order number of the manipulator corresponds to the
DX100. The order number is located on a label as shown below.
Fig. 1-1: Location of Order Number Labels
PROPERLY.
CHECK ALL THE DOOR LOCKS
NJ3005-1
AVERAGE
PEAK
kVA
kA
INTERRUPT CURRENT
ERDR-
POWER SUPPLY
TYPE
DX100
kVA
3PHASE
NJ2960-1
60Hz
SERIAL No.
DATE
AC220V
MADE IN JAPAN
50/60HzAC200V
PROGRAMMING PENDANT
Y
C
E
G
N
O
T
P
M
E
E
S
R
ON
TRIPPED
RESET
OFF
THE MANIPULATOR AND THE CONTROLLER
SHOULD HAVE SAME ORDER NUMBER.
ORDER NO.
Check that the manipulator
and the DX100 have the
same order number.
Label (Enlarged View)
(a) DX100 (Front View) (b) Manipulator (Side View)
WARNING
Do not open the door
To Next Page
