8-1
157569-1CD
HW0485652
MPL100
8 Electrical Equipment Specification
8.1 Position of Limit Switch
8 Electrical Equipment Specification
8.1 Position of Limit Switch
The limit switches are optional. For the S-, L-, and U-axes with limit
switches specifications, the limit switches are located on the S-axis,
L-axis, and U-axis respectively. For the location, refer to Fig. 8-1
“Location of Limit Switches”.
Fig. 8-1: Location of Limit Switches
L- and U-axes interference
limit switch (optional)
L-axis overrun
limit switch (optional)
S-axis overrun
limit switch (optional)
A
To Next Page
