2.2 Detail Definition Setting Procedures
218IFD Detail Definition Dialog Box Details
2-14
Node Name (Remote Station Name)
Used to enter a comment for the connection.
Enter a comment of up to 32 characters.
Write-in width
of Coil/Hold
Register, LO
MW00000 to
MW1048576
Sets the low end of the range for writ-
ing hold registers (coils) that are used
with automatic reception.
MW00000
Write-in width
of Coil/Hold
Register, HI
MW00000 to
MW1048576
Sets the high end of the range for writ-
ing hold registers (coils) that are used
with automatic reception.
MW1048575
Write-in width
of Data Relay/
Register, LO
GW00000 to
GW2097151
Sets the low end of the range for writ-
ing data registers (data relays) that are
used with automatic reception.
GW00000
Write-in width
of Data Relay/
Register, HI
GW00000 to
GW2097151
Sets the high end of the range for writ-
ing data registers (data relays) that are
used with automatic reception.
GW2097151
Write-in width
of Output Coil/
Register, LO
OW00000 to OW17FFF
Sets the low end of the range for writ-
ing output registers (output coils) that
are used with automatic reception.
OW00000
Write-in width
of Output Coil/
Register, HI
OW00000 to OW17FFF
Sets the high end of the range for writ-
ing output registers (output coils) that
are used with automatic reception.
OW17FFF
Automatic input
processing
delay time
0 to 100 (ms)
Sets the delay time for sending
responses to adjust the influence on the
low-speed scan during automatic
reception processing.
0
