4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-60
Automatic Reception Status for Ethernet Communications
The data in these registers give the execution status of automatic reception.
Name Register Address Contents
Circuit
Number 1
Common
Status
SW25000 Rack No.
SW25001 Unit No.
SW25002 Slot No.
SW25003 Sub-slot No.
CH1 Status
SW25004
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25005
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25006 Transmission pass counter
SW25007 Reception pass counter
SW25008 Error counter
SW25009 to
SW25011
Reserved for system.
CH2 Status
SW25012 to
SW25019
Same as CH1 status.
CH3 Status
SW25020 to
SW25027
Same as CH1 status.
CH4 Status
SW25028 to
SW25035
Same as CH1 status.
CH5 Status
SW25036 to
SW25043
Same as CH1 status.
CH6 Status
SW25044 to
SW25051
Same as CH1 status.
CH7 Status
SW25052 to
SW25059
Same as CH1 status.
CH8 Status
SW25060 to
SW25067
Same as CH1 status.
CH9 Status
SW25068 to
SW25075
Same as CH1 status.
CH10 Status
SW25076 to
SW25083
Same as CH1 status.
Continued on next page.
