4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-61
Circuit
Number 2
Common
Status
SW25084 Rack No.
SW25085 Unit No.
SW25086 Slot No.
SW25087 Sub-slot No.
CH1 Status
SW25088
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25089
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25090 Transmission pass counter
SW25091 Reception pass counter
SW25092 Error counter
SW25093 to
SW25095
Reserved for system.
CH2 Status
SW25096 to
SW25103
Same as CH1 status.
CH3 Status
SW25104 to
SW25111
Same as CH1 status.
CH4 Status
SW25112 to
SW25119
Same as CH1 status.
CH5 Status
SW25120 to
SW25127
Same as CH1 status.
CH6 Status
SW25128 to
SW25135
Same as CH1 status.
CH7 Status
SW25136 to
SW25143
Same as CH1 status.
CH8 Status
SW25144 to
SW25151
Same as CH1 status.
CH9 Status
SW25152 to
SW25159
Same as CH1 status.
CH10 Status
SW25160 to
SW25167
Same as CH1 status.
Continued on next page.
Continued from previous page.
Name Register Address Contents
To Next Page
