4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-62
Circuit
Number 3
Common
Status
SW25168 Rack No.
SW25169 Unit No.
SW25170 Slot No.
SW25171 Sub-slot No.
CH1 Status
SW25172
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25173
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25174 Transmission pass counter
SW25175 Reception pass counter
SW25176 Error counter
SW25177 to
SW25179
Reserved for system.
CH2 Status
SW25180 to
SW25187
Same as CH1 status.
CH3 Status
SW25188 to
SW25195
Same as CH1 status.
CH4 Status
SW25196 to
SW25203
Same as CH1 status.
CH5 Status
SW25204 to
SW25211
Same as CH1 status.
CH6 Status
SW25212 to
SW25219
Same as CH1 status.
CH7 Status
SW25220 to
SW25227
Same as CH1 status.
CH8 Status
SW25228 to
SW25235
Same as CH1 status.
CH9 Status
SW25236 to
SW25243
Same as CH1 status.
CH10 Status
SW25244 to
SW25251
Same as CH1 status.
Continued on next page.
Continued from previous page.
Name Register Address Contents
