4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-63
Circuit
Number 4
Common
Status
SW25252 Rack No.
SW25253 Unit No.
SW25254 Slot No.
SW25255 Sub-slot No.
CH1 Status
SW25256
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25257
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25258 Transmission pass counter
SW25259 Reception pass counter
SW25260 Error counter
SW25261 to
SW25263
Reserved for system.
CH2 Status
SW25264 to
SW25271
Same as CH1 status.
CH3 Status
SW25272 to
SW25279
Same as CH1 status.
CH4 Status
SW25280 to
SW25287
Same as CH1 status.
CH5 Status
SW25288 to
SW25295
Same as CH1 status.
CH6 Status
SW25296 to
SW25303
Same as CH1 status.
CH7 Status
SW25304 to
SW25311
Same as CH1 status.
CH8 Status
SW25312 to
SW25319
Same as CH1 status.
CH9 Status
SW25320 to
SW25327
Same as CH1 status.
CH10 Status
SW25328 to
SW25335
Same as CH1 status.
Continued on next page.
Continued from previous page.
Name Register Address Contents
