4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-64
Circuit
Number 5
Common
Status
SW25336 Rack No.
SW25337 Unit No.
SW25338 Slot No.
SW25339 Sub-slot No.
CH1 Status
SW25340
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25341
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25342 Transmission pass counter
SW25343 Reception pass counter
SW25344 Error counter
SW25345 to
SW25347
Reserved for system.
CH2 Status
SW25348 to
SW25355
Same as CH1 status.
CH3 Status
SW25356 to
SW25363
Same as CH1 status.
CH4 Status
SW25364 to
SW25371
Same as CH1 status.
CH5 Status
SW25372 to
SW25379
Same as CH1 status.
CH6 Status
SW25380 to
SW25387
Same as CH1 status.
CH7 Status
SW25388 to
SW25395
Same as CH1 status.
CH8 Status
SW25396 to
SW25403
Same as CH1 status.
CH9 Status
SW25404 to
SW25411
Same as CH1 status.
CH10 Status
SW25412 to
SW25419
Same as CH1 status.
Continued on next page.
Continued from previous page.
Name Register Address Contents
