3.1 Basic Functionality
3.1.1 Programs
3-7
3
CPU Module Functionality
The following figure shows an execution example.
The ladder instruction in the H drawing is executed every high-speed scan cycle according to
the hierarchical organization of parent-child-grandchild drawings.
The above programming only prepares for execution of the motion program. The motion pro-
gram is not executed when the MSEE instruction is inserted. To start the motion program after
inserting the MSEE instruction, use a control signal to turn ON the Request for Start of Program
Operation.
The motion program is executed in the scan cycle, but unlike ladder programs, the entire pro-
gram is not executed in a single scan. Motion programs are controlled specifically by the sys-
tem’s motion management.
The following points must be taken into consideration when executing motion programs.
• Motion programs that are registered in the M-EXECUTOR cannot be executed with MSEE
instructions.
• More than one instance of the same motion program (i.e., the same program number) cannot
be executed with MSEE instructions.
• Subprograms (MPS) cannot be executed with MSEE instructions in a ladder program.
You can call subprograms only from motion programs and motion subprograms (MPM
and MPS).
• You cannot call the same subprogram more than once at the same time.
• Sequence programs (SPM or SPS) cannot be called with MSEE instructions from a
ladder program.
MSEE
MPM001
DWG.H
SEE
H01
DEND
DWG.H01
SEE H01.01
END
DEND
END
RETEND
DEND
MPM003
MPS101
DWG.H01.01
MPM001
MPM002
MSEE
MPM002
MSEE
MPM003
MSEE
MPS101
VEL [a1]5000 [b1]..
FMX T10000000;
IAC T25;
IDC T30;
MOV [a1]300. [b1]..
MVS [a1]200. [b1]..
Execution is started by
the system program
when the execution
condition is met.
Parent drawing
Child drawing
Grandchild drawing
Motion programs
Subprogram
Note
