4.2Servomotor Ratings and Characteristics
— 4-11 —
4.2 Servomotor Ratings and Characteristics
This section provides tables of ratings, specifications, and machine characteristics for
Servomotors. Refer to these tables when selecting a Servo Drive.
4.2.1 Ratings and Specifications
24-VDC Servomotors (j15)
Time rating: Continuous
Thermal class: B
Vibration class: 15µm or below
Withstand voltage: 550 VAC for one minute
Insulation resistance: 500 VDC 10 MΩ min.
Enclosure: Totally enclosed, self-cooled
Ambient temperature: 0°Cto40°C
Ambient humidity: 20% to 80% (non-condensing)
Excitation: Permanent magnet
Drive method: Direct drive
Mounting: Flange method
Standard Servomotors
SGMM Servomotor
B3CF1j B5CF1j B9CF1j
Rated Output
*1
W (HP) 3 (0.004) 5 (0.007) 10 (0.013)
Rated Torque
*1
N¡m
0.00955 0.0159 0.0318
q
oz¡in
*2
1.35 2.25 4.5
Instantaneous Peak Torque
*1
N¡m
0.0239 0.0398 0.0796
q
oz¡in
*2
3.39 5.64 11.3
Rated Current
*1
A (rms) 1.3 1.3 1.5
Instantaneous Maximum
Current
*1
A (rms) 3.5 3.6 3.9
Rated Speed
*1
min
−1
3000
Instantaneous Maximum
Speed
*1
min
−1
6000
Applicable Encoder --- 1024 P/R Incremental encoder
Moment of Inertia
[J
GD
2
/]
¢10
−4
kg¡m
2
0.0004 0.0008 0.0022
[J
M
=GD
2
M
/4]
(
×
10
−3
oz¡in¡s
2
)
*2
0.0057 0.0113 0.0311
Rated Angular Acceleration
*1
rad/s
2
239000 199000 145000
Rated Power Rate
*1
kW/s 2.3 3.2 4.6
*
1
These items and torque-speed characteristics are quoted in combination with an SGDF
SERVOPACK at an armature winding temperature of 20°C.
