YASKAWA Sigma Mini SGMM Series - Connection and Wiring

BASIC OPERATION
1.3.1 Connecting to Peripheral Devices
— 1-12 —
1.3 Connection and Wiring
This section describes how to connect Σ-Series products to peripheral devices and
explains a typical example of wiring the main circuit. It also describes an example of
connecting to main host controllers.
1.3.1 Connecting to Peripheral Devices
This section shows a standard example of connecting Σ-Series products to peripheral de-
vices and briefly explains which peripheral devices can be connected and in which locations
to connect them.
1
