YASKAWA V1000

5 Main Circuit and Motor Wiring
16 YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide
BA0010
R/L1, S/L2, T/L3 10 14 to 10
B010
L/L1, N/L2 10 12 to 10 8
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 14 14 to 12 8
-, +1, +2 – 14 to 10 -, +1 10 12 to 10 8
B1, B2 – 14 to 10 B1, B2 14 14 to 12 8
Ground 10 14 to 10 Ground 10 14 to 10 -
BA0012
R/L1, S/L2, T/L3 10 14 to 10
B012
L/L1, N/L2 8 14 to 8 10
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 12 14 to 10 10
-, +1, +2 – 14 to 10 -, +1 8 14 to 8 10
B1, B2 – 14 to 10 B1, B2 14 14 to 12 10
Ground 10 14 to 10 Ground 10 14 to 10 -
BA0018
R/L1, S/L2, T/L3 8 12 to 8
B018
L/L1, N/L2 8 12 to 6 10
U/T1, V/T2, W/T3 10 12 to 8 U/T1, V/T2, W/T3 10 14 to 8 10
-, +1, +2 – 12 to 8 -, +1 8 12 to 6 10
B1, B2 – 12 to 8 B1, B2 14 14 to 12 10
Ground 8 12 to 8 Ground 8 12 to 8 -
Three-Phase 240 V Models
2A0001
2A0002
2A0004
2A0006
R/L1, S/L2, T/L3 14 18 to 14
2001
2002
2004
2006
R/L1, S/L2, T/L3 14 14 6.5
U/T1, V/T2, W/T3 14 18 to 14 U/T1, V/T2, W/T3 14 14 6.5
-, +1, +2 – 18 to 14 -, +1, +2 14 14 6.5
B1, B2 – 18 to 14 B1, B2 14 14 6.5
Ground 14 18 to 14 Ground 14 14 -
2A0010
R/L1, S/L2, T/L3 12 14 to 10
2010
R/L1, S/L2, T/L3 14 14 to 12 8
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 14 14 to 12 8
-, +1, +2 – 14 to 10 -, +1, +2 12 14 to 10 8
B1, B2 – 14 to 10 B1, B2 14 14 to 12 8
Ground 10 14 to 10 Ground 10 14 to 10 -
2A0012
R/L1, S/L2, T/L3 12 14 to 10
2012
R/L1, S/L2, T/L3 12 14 to 10 8
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 12 14 to 10 8
-, +1, +2 – 14 to 10 -, +1, +2 10 12 to 10 8
B1, B2 – 14 to 10 B1, B2 14 14 to 12 8
Ground 10 14 to 10 Ground 10 14 to 10 -
2A0020
R/L1, S/L2, T/L3 10 14 to 10
2021
R/L1, S/L2, T/L3 8 14 to 8 10
U/T1, V/T2, W/T3 10 14 to 10 U/T1, V/T2, W/T3 10 14 to 8 10
-, +1, +2 – 14 to 10 -, +1, +2 8 14 to 8 10
B1, B2 – 14 to 10 B1, B2 14 14 to 10 10
Ground 10 14 to 10 Ground 8 14 to 8 -
2A0030
R/L1, S/L2, T/L3 8 10 to 6
2030
R/L1, S/L2, T/L3 8 12 to 6 10
U/T1, V/T2, W/T3 8 10 to 6 U/T1, V/T2, W/T3 8 12 to 6 10
-, +1, +2 – 10 to 6 -, +1, +2 6 12 to 6 10
B1, B2 – 14 to 10 B1, B2 12 12 to 8 10
Ground 8 10 to 6 Ground 8 10 to 6 -
2A0040
R/L1, S/L2, T/L3 6 10 to 6
2042
R/L1, S/L2, T/L3 6 12 to 6 10
U/T1, V/T2, W/T3 8 10 to 6 U/T1, V/T2, W/T3 6 12 to 6 10
-, +1, +2 – 10 to 6 -, +1, +2 4 10 to 2 18
B1, B2 – 14 to 10 B1, B2 10 14 to 6 10
Ground 6 10 to 6 Ground 6 10 to 6 -
V1000 GA500
Drive Model
CIMR-VU_
Terminal
Recom-
mended
Gauge
AWG
Wire Range
AWG
Catalog
Code
GA50U_
Terminal
Recom-
mended
Gauge
AWG
Wire Range
AWG
Wire
Stripping
Length
mm
