YASKAWA V1000

5 Main Circuit and Motor Wiring
YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide 17
2A0056
R/L1, S/L2, T/L3 4 6 to 4
2056
R/L1, S/L2, T/L3 4 10 to 2 18
U/T1, V/T2, W/T3 4 6 to 4 U/T1, V/T2, W/T3 4 10 to 2 18
-, +1, +2 – 6 to 4 -, +1, +2 2 8 to 2 18
B1, B2 – 10 to 6 B1, B2 8 12 to 6 10
Ground 6 8 to 4 Ground 6 8 to 4 -
2A0069
R/L1, S/L2, T/L3 3 8 to 2
2070
R/L1, S/L2, T/L3 2 6 to 1 20
U/T1, V/T2, W/T3 3 8 to 2 U/T1, V/T2, W/T3 2 8 to 1 20
-, +1, +2 – 8 to 2 -, +1, +2 1 6 to 1/0 20
B1, B2 – 8 to 6 B1, B2 8 12 to 6 10
Ground 6 6 to 4 Ground 4 6 to 4 -
– 2082
R/L1, S/L2, T/L3 1 6 to 1/0 20
U/T1, V/T2, W/T3 2 6 to 1 20
-, +1, +2 2/0 2 to 2/0 20
B1, B2 6 10 to 6 10
Ground 4 6 to 4 -
Three-Phase 480 V Models
4A0001
4A0002
4A0004
R/L1, S/L2, T/L3 14 14 to 10
4001
4002
R/L1, S/L2, T/L3 14 14 to 12 8
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 14 14 to 12 8
-, +1, +2 – 14 to 10 -, +1, +2 14 14 to 12 8
B1, B2 – 14 to 10 B1, B2 14 14 to 12 8
Ground 14 14 to 10 Ground 14 14 to 10 -
4004
R/L1, S/L2, T/L3 14 14 to 12 8
U/T1, V/T2, W/T3 14 14 to 12 8
-, +1, +2 14 14 to 12 8
B1, B2 14 14 to 12 8
Ground 10 14 to 10 -
4A0005
4A0007
4A0009
R/L1, S/L2, T/L3 14 14 to 10
4005
4007
4009
R/L1, S/L2, T/L3 14 14 to 12 8
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 14 14 to 12 8
-, +1, +2 – 14 to 10 -, +1, +2 14 14 to 12 8
B1, B2 – 14 to 10 B1, B2 14 14 to 12 8
Ground 10 14 to 10 Ground 10 14 to 10 -
4A0011
R/L1, S/L2, T/L3 12 14 to 10
4012
R/L1, S/L2, T/L3 12 14 to 10 10
U/T1, V/T2, W/T3 14 14 to 10 U/T1, V/T2, W/T3 14 14 to 12 10
-, +1, +2 – 14 to 10 -, +1, +2 10 12 to 8 10
B1, B2 – 14 to 10 B1, B2 14 14 to 12 10
Ground 10 14 to 10 Ground 10 14 to 10 -
4A0018
R/L1, S/L2, T/L3 10 14 to 6
4018
R/L1, S/L2, T/L3 10 12 to 8 10
U/T1, V/T2, W/T3 10 14 to 6 U/T1, V/T2, W/T3 10 12 to 8 10
-, +1,+2 – 14 to 6 -, +1, +2 10 14 to 8 10
B1, B2 – 14 to 10 B1, B2 14 14 to 12 10
Ground 8 14 to 6 Ground 10 14 to 6 -
4A0023
R/L1, S/L2, T/L3 10 10 to 6
4023
R/L1, S/L2, T/L3 8 14 to 6 10
U/T1, V/T2, W/T3 10 10 to 6 U/T1, V/T2, W/T3 10 14 to 8 10
-, +1, +2 – 10 to 6 -, +1, +2 8 12 to 6 10
B1, B2 – 14 to 10 B1, B2 12 14 to 10 10
Ground 8 10 to 6 Ground 10 10 to 6 -
V1000 GA500
Drive Model
CIMR-VU_
Terminal
Recom-
mended
Gauge
AWG
Wire Range
AWG
Catalog
Code
GA50U_
Terminal
Recom-
mended
Gauge
AWG
Wire Range
AWG
Wire
Stripping
Length
mm
