YASKAWA V1000

5 Main Circuit and Motor Wiring
18 YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide
4A0031
R/L1, S/L2, T/L3 8 10 to 6
4031
R/L1, S/L2, T/L3 8 12 to 6 10
U/T1, V/T2, W/T3 8 10 to 6 U/T1, V/T2, W/T3 8 12 to 6 10
-, +1, +2 – 10 to 6 -, +1, +2 6 12 to 4 18
B1, B2 – 14 to 10 B1, B2 10 12 to 8 10
Ground 6 10 to 6 Ground 8 10 to 6 -
4A0038
R/L1, S/L2, T/L3 6 10 to 6
4038
R/L1, S/L2, T/L3 6 12 to 6 10
U/T1, V/T2, W/T3 8 10 to 6 U/T1, V/T2, W/T3 8 12 to 6 10
-, +1, +2 – 10 to 6 -, +1, +2 4 10 to 2 18
B1, B2 – 10 to 8 B1, B2 10 14 to 6 10
Ground 6 10 to 6 Ground 6 10 to 6 -
– 4044
R/L1, S/L2, T/L3 4 10 to 2 18
U/T1, V/T2, W/T3 6 12 to 4 18
-, +1, +2 2 8 to 2 18
B1, B2 8 12 to 6 10
Ground 6 10 to 6 -
– 4060
R/L1, S/L2, T/L3 2 8 to 2 18
U/T1, V/T2, W/T3 4 10 to 2 18
-, +1, +2 2 6 to 2 18
B1, B2 8 12 to 6 10
Ground 6 10 to 6 -
V1000 GA500
Drive Model
CIMR-VU_
Terminal
Recom-
mended
Gauge
AWG
Wire Range
AWG
Catalog
Code
GA50U_
Terminal
Recom-
mended
Gauge
AWG
Wire Range
AWG
Wire
Stripping
Length
mm
