Yealink CTP20 User Manual

| Managing the Directory | 228
Parameter Description Configuration Method
LDAP Name Filter
Configure the name attribute for
LDAP searching.
Example: (|(cn=%)(sn=%))
Web user interface
LDAP Number Filter
Configure the number attribute
for LDAP searching.
Example: (|(telephoneNumber=
%)(mobile=%))
Web user interface
LDAP TLS Mode
Configure the connection mode
between the LDAP server and
the system.
• LDAP—Unencrypted
connection between LDAP
server and the system (port
389 is used by default).
• LDAP TLS Start- TLS/SSL
connection between LDAP
server and the system (port
389 is used by default).
• LDAPs- TLS/SSL connection
between LDAP server and
the system (port 636 is used
by default).
Default: LDAP
Web user interface
LDAP Server Address Configure the domain name
or the IP address of the LDAP
server.
Web user interface
Port
Configure the LDAP server port.
Default: 389.
Web user interface
LDAP User Name
Configure the user name used to
log into the LDAP server.
Note: the user name is
provided by the LDAP server
administrator. If the LDAP server
allows ‘anonymous’ to login,
you don’t need to provide the
user name to access the LDAP
server.
Web user interface

Yealink CTP20 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Multi-user
Touchscreen technology	Capacitive
Number of simultaneous touchpoints	10
Product color	Black
Power consumption (typical)	7 W
Ethernet LAN (RJ-45) ports	1
OmniTapps Multitouch compatibility	No
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (without stand)	196 mm
Width (without stand)	321.5 mm
Height (without stand)	118 mm
