Yealink SIP-T38G Manual

Gigabit Color IP Phone Customizing Your Phone
Address
To configure PC Port settings via Phone interface:
1) Press Menu->Setting->Advanced Settings.
2) Enter the password required, scroll to Network option, select PC Port option.
3) If you choose Bridge, set the PC’s port as bridge mode, and then it will save and
return to the previous menu.
4) If you choose Router, you will be prompted to enter the IP Address, Subnet Mask,
DHCP Server Disable/Enable, etc.
5) Press Save soft key to save the changes.
To configure PC Port settings via Web interface:
Choose Network->Basic->LAN to do the relating configuration, you can consult your
system administrator for more information.
Webserver Type
It is the definition of web access type and port. This IP phone can support HTTPS
(Hypertext Transfer Protocol over Secure Socket Layer) and HTTP. Adding SSL layer
under HTTP, in short, it is a security version of HTTP. Users can set this transmission
mode via web page.
To configure HTTPS settings via Phone interface:
1) Press Menu->Setting->Advanced Settings.
2) Enter the password required, scroll to Network option, select Webserver Type

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
