Yealink SIP-T38G Manual

Gigabit Color IP Phone Customizing Your Phone
into the advanced settings page must input administrator password at first.
Account
Please refer to the previous part “Configuration and Registration” for the basic Account
setting information.
Network
WAN Port
Please refer to the previous part “Configuration and Registration” for the basic WAN
setting information.
PC Port
The following table lists the instructions of the field about the Network PC Port Setting.
Field Name
Description
As Bridge
If you select the Bridge mode, then the two Fast Ethernet ports will
be transparent.
As Router
If you select the Router mode, the SIP phone will work as a router.
--IP address
User could configure the PC port IP address.
--Subnet Mask
User could configure the PC port Subnet Mask.
--DHCP Server
If you set the DHCP server on, the device connected to the PC port
will get the IP address automatically between the start IP address
and the end IP address. But if you select the bridge mode, the DHCP
server cannot work.
--Start IP
Address
Indicate the range of the IP address.
--End IP
Indicate the range of the IP address.

Yealink SIP-T38G Specifications

General

Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Keypad number of keys	48
Touchscreen	-
Display resolution	480 x 272 pixels
Display number of colors	16.78 million colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723.1, G.726
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4.6 W
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	204 mm
Width	273 mm
Height	42 mm
Weight	1050 g
