Yealink SIP-T42S User Manual

User Guide for the SIP-T42S IP Phone
110
to be *71 (may vary on different servers), and the target number to be 1234. When you activate
Always Forward on the IP phone, the IP phone sends *711234 to the server, and then the server
will activate Always Forward feature on the server side, hence being able to get the right status
of the extension.
Call forward is configurable via web user interface at the path Features->Forward&DND.
Note
To configure the forward authorized numbers via web user interface:
1. Click on Features->Forward&DND.
2. Select Enabled from the pull-down list of Forward Emergency.
3. Enter the numbers in the Forward Authorized Numbers field.
For multiple numbers, enter a comma between every two numbers.
4. Click Confirm to accept the change.
When call forward is activated on the phone, the phone cannot forward incoming calls from
the numbers specified in the Forward Authorized Numbers field
Note
You can also enter the SIP URI or IP address in the Forward to field. For more information on
using the SIP URI or IP address, refer to Placing Calls on page 92.
Call forward is local to the phone, and may be overridden by the server settings. Call forward on
code or off code may be different between servers. For more information, contact your system
administrator.
Forward authorized number is configurable via web user interface only.

Yealink SIP-T42S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	6
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
