Yealink SIP-T42S User Manual

User Guide for the SIP-T42S IP Phone
122
The phone will dial the configured park retrieve code and the Retrieve screen appears as
below:
2. Follow the voice prompt, do one of the following:
- Press on the phone where the call is parked.
- Enter the desired extension followed by # (e.g., 4603#) on any phone.
Note
Transfer Mode
To configure call park feature in transfer mode via web user interface:
1. Click on Features->Call Pickup.
2. Select Transfer from the pull-down list of Call Park Mode.
3. Select Enabled from the pull-down list of Call Park.
If Enabled is selected, the Park soft key will display on the LCD screen during a call, and
the Retrieve soft key will display on the dialing screen.
4. (Optional.) Enter the call park code in the Call Park Code field.
It is configured for the Park soft key. This call park code will also apply to the call park key.
5. (Optional.) Enter the park retrieve code in the Park Retrieve Code field.
You can also press the desired BLF or BLF list key to park a call or retrieve a parked call directly.
For more information, refer to Parking a Call/Retrieving a Parked Call to the Monitored User
on
page 137.

Yealink SIP-T42S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	6
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
