Customizing Your Phone
59
Placing a Call from History Records
To place a call from the call history list:
1. Press the History soft key.
2. Press or to switch among all, missed, placed, received and forwarded call lists.
3. Press or to select the desired entry.
4. Press the Send soft key.
Adding a Contact to the Local Directory/Blacklist
To add a contact to the local directory (or blacklist directory) from the call history list:
1. Press the History soft key.
2. Press or to switch among all, missed, placed, received and forwarded call lists.
3. Press or to select the desired entry.
4. Press the Option soft key, and then select Add to Contact (or Add to Blacklist).
5. Enter the desired values in the corresponding fields.
6. Press the Save soft key to accept the change.
For more information on local directory and/or blacklist, refer to Local Directory on page 47
and/or Blacklist on page 55.
Deleting History Records
To delete an entry from the call history list:
1. Press the History soft key.
2. Press or to switch among all, missed, placed, received and forwarded call lists.
3. Press or to select the desired entry.
4. Press the Delete soft key.
To delete all entries from the call history list:
1. Press the History soft key.
2. Press or to switch among all, missed, placed, received and forwarded call lists.
3. Press the Option soft key, and then select Delete All.
4. Press the OK soft key.
