User Guide for the SIP-T42S IP Phone
124
Call Pickup
You can use call pickup to answer someone else’s incoming call on your phone. The SIP-T42S IP
phone supports directed call pickup and group call pickup. Directed call pickup is used for
picking up a call that is ringing at a target phone number. Group call pickup is used for picking
up a call that is ringing at any phone number in a certain group. The pickup group should be
predefined, contact your system administrator for more information.
You can pick up an incoming call by using the DPickup/GPickup soft key. To use call pickup,
you need to configure the call pickup code beforehand on a global or per-line basis via web
user interface.
Note
Directed Call Pickup
To enable directed call pickup and configure the directed call pickup code on a global
basis via web user interface:
1. Click on Features->Call Pickup.
2. Select Enabled from the pull-down list of Directed Call Pickup.
3. Enter the directed call pickup code in the Directed Call Pickup Code field.
4. Click Confirm to accept the change.
To configure the directed call pickup code on a per-line basis via web user interface:
1. Click on Account->Advanced.
2. Select the desired account from the pull-down list of Account.
If there are many incoming calls at the same time, pressing the GPickup soft key on the phone
will pick up the call that rings first.

Table of Contents

Other manuals for Yealink SIP-T42S

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T42S and is the answer not in the manual?

Yealink SIP-T42S Specifications

General IconGeneral
ManualYes
Cables includedLAN (RJ-45)
Number of handles included1 pc(s)
Lines quantity12 lines
Phonebook capacity1000 entries
Number of VoIP accounts12
MountingDesk/Wall
Handset typeWired handset
Product typeIP Phone
Product colorBlack
Voice codecsCNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 95 %
Display diagonal2.7 \
Display resolution192 x 64 pixels
AC adapter input voltage100 - 240 V
AC adapter output current1.2 A
AC adapter output voltage5 V
Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
Volume controlDigital
Number of programmable keys6
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
Networking standardsIEEE 802.3af
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Supported network protocolsSIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Weight and Dimensions IconWeight and Dimensions
Depth189 mm
Width212 mm
Height175 mm
Package depth223 mm
Package width246 mm
Package height120 mm
