Yealink SIP-T42S User Manual

Advanced Phone Features
133
4. Click Confirm to accept the change.
Note
To configure BLF ring type via phone user interface:
1. Press Menu->Settings->Basic Settings->Sound->BLF Ring Type.
2. Press or to select the desired ring tone.
3. (Optional.) Press to adjust the ringer volume.
4. Press the Save soft key to accept the change or the Back soft key to cancel.
BLF ring type is configurable via web user interface at the path Features->Call Pickup.
When the monitored line receives an incoming call, the following occurs on your phone:
 The phone plays a specific ring tone (if enabled).
 The BLF key LED flashes red.
 The caller ID appears on the LCD screen (if enabled).
In the following figure, the LCD screen shows an incoming call from 1079 on the monitored line.
You can do the following actions:
- Press the Pick Up soft key to pick up the call.
- Press the Send soft key to dial out the monitored phone number.
- Press the New Call soft key to place a new call.
- Press the Cancel soft key to exit the screen.
Note
Configuring Directed Call Pickup Code
If you configure the directed call pickup code in advance, you can pick up the monitored user’s
If your phone is locked and the type of the phone lock is configured as Function Keys or All
keys, you cannot use the DPickup, Send, New Call and Cancel soft keys until unlocked. For
more information, refer to Phone Lock on page 40.
Visual and audio alert features are configurable via web user interface only.

Yealink SIP-T42S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	6
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
