Customizing Your Phone
53
- If multiple numbers for the contact are stored in the local directory, press the Send soft
key to display a list of numbers.
Press or to highlight the desired number.
Press the Send soft key to dial out the number.
Searching for Contacts
To search for a contact in the local directory:
1. Press the Directory soft key.
The IP phone enters the local directory directly as there is only Local Directory enabled in
the directory by default.
If Local Directory is removed from the directory (refer to Directory on page 45), press
Menu->Directory->Local Directory to enter the local directory.
2. Press the Search soft key.
3. Enter a few continuous characters of the contact name or continuous numbers of the
contact number (office, mobile or other number) using the keypad.
The contacts whose name or phone number matches the characters entered will appear on
the LCD screen. You can dial from the result list.
Importing/Exporting Contact Lists
You can manage your phone’s local directory via phone user interface or web user interface. But
you can only import or export the contact list via web user interface.
To import an XML contact list file via web user interface:
1. Click on Directory->Local Directory.
2. Click Browse to locate a contact list file (the file format must be *.xml) from your local
system.
