Yeastar Technology S20 Administrator's Guide

S-Series IP PBX Administrator Guide
116
To import a phone book:
1) Click , you will see a dialog window shown as below.
Figure 17-5 Import LDAP Phonebook
2) Click and select the file to start uploading. The file must be a .csv file. Check the
sample file below. You can export a phone book file from S-Series and use it as a sample to start
with.
Figure 17-6 Phonebook File
To export a phone book:
Select the checkbox of the phone book, click , the selected phone book will be exported to
your local PC.
Figure 17-7 Export LDAP Phonebook
3. Configure LDAP Settings on Your Phone
Here we take Yealink T-26 IP Phone (Version 6.73.0.50) as an example.
NOTE:
Operations may be different for different IP phone with different version.

Yeastar Technology S20 Specifications

General

Brand	Yeastar Technology
Model	S20
Category	PBX
Language	English
