Yeastar Technology S20 Administrator's Guide

S-Series IP PBX Administrator Guide
70
2) Import Blacklist/Whitelist
Click , you will see a dialog window shown as below.
Figure 7-10 Import Blacklist
Click and select the file to start uploading. The file must be a .csv file. Open the file
with notepad, check the sample below. You can export a blacklist/whitelist file from S-Series and
use it as a sample to start with.
Figure 7-11 Blacklist/Whitelist File
The sample csv file will result in the following speed dial in Yeastar S-Series.
Figure 7-12 Blacklist/Whitelist
10) Export Blacklist/Whitelist
Select the checkbox of the blacklist/whitelist, click , the selected blacklist/whitelist will
be exported to your local PC.
Pin List
PIN List is used to manage lists of PINs (numerical passwords) that can be used to access restricted
