S-Series IP PBX Administrator Guide
40
Bind Consecutive DOD Numbers to Multiple Extensions
Enter the DOD number range and select the extensions.
Figure 5-2 Bind Consecutive DOD Numbers to Multiple Extensions
GSM/CDMA/3G Trunk
Yeastar S-Series supports GSM/CDMA/3G trunk. To extend the trunk, you need to install
GSM/CDMA/3G module to the S-Series and insert SIM card on the module.
Click to edit the trunk. Please check the GSM/CDMA/3G trunk configuration parameters below.
Table 5-7 GSM/CDMA/3G Trunk Configuration Parameters
Give this trunk a name to help you identify this trunk.
Enter the SIM card PIN code if the card has one.
Note: if you failed to enter your correct PIN code 3 times in succession, the
SIM card will be permanently locked, which means you would need a new
card.
Set the receiving volume of GSM port or choose Custom to define the RX
gain below.
The RX Gain for the receiving channel of GSM Port. The valid range is
-20db to 20db.
Set the transmitting volume of GSM port or choose Custom to define the TX
gain below.
The TX Gain for the transmitting channel of GSM Port. The valid range is
-20db to 20db.
Dialed Number Identification Service is a telephone service that enables a
company to identify which telephone number was dialed. Users could
configure DNIS to allow the IP phones to display which trunk is passing the
call.
