6-5
IM CA500-01EN
Other Settings
6
6.4 Setting the Decimal Symbol and CSV Separator
Procedure
1.
With the source value and measurement value displayed, press MENU. A menu screen
appears.
2.
Use the cursor keys to select Device Setup, and then press ENTER. A Device Setup screen
appears.
3.
Press the cursor keys several times to display Device Setup 2/2.
Decimal Symbol
4.
User cursor keys to select Decimal Point. PERIOD ( . ) and COMMA ( , ) appear on the
selection menu.
Set the decimal symbol.
Set the CSV separator.
5.
Use the arrow keys to set the symbol to use for the decimal point.
To finish entering the settings here, proceed to step 8.
CSV Separator
6.
Use the cursor keys to select CSV Separator. COMMA ( , ), SEMI COLON ( ; ) and TAB appear
on the selection menu.
7.
Use the cursor keys to set the symbol to use for the CSV separator.
Confirming the Settings
8.
Press the arrow key corresponding to EXIT SETUP. The settings are confirmed, and a screen
appears showing the source value and measurement value.
Pressing ESC causes the instrument to discard the settings and return to the menu screen.
To initialize the settings, pressing the arrow key corresponding to INIT SETUP.
Description
Set the decimal symbol and CSV separator that are used when saving the data sourced and
measured by this instrument.
Data can be saved according to the specifications of the software that the data will be used in.
