Saving Data
5.3 Loading and Deleting Saved Data
Procedure
1.
With the source value and measurement value displayed, press LOAD. A list of saved data is
displayed.
On the CA500, a list of data saved using the SAVE key is displayed. On the CA550, a list of
CSV files saved using program sweeps is displayed.
CA500
CA550
2.
Use the cursor keys to select the data you want to load, and then press ENTER.
The screen displays the loaded source value and measurement value (“LOAD” appears at the
top of the screen).
Function 1 data
Function 2 data
Memory number
LOAD is displayed on the load screen.
CA500
CA550
The specified step in the program sweep
Measurement value of each step
Error relative to the reference value
3.
Use the cursor keys to change the displayed data.
4.
On the CA500, when you press ENTER, the settings in the loaded file are applied to the
CA500.
5.
When you press ESC, the screen returns to the overview screen of step 1.
