Saving Data Using Program Sweep
Saved data Notes
MODEL CA550
FILE TYPE 0: Manually saved data using the SAVE key
1: Automatically saved data by a step sweep
2: Calibration data by a program sweep
CSV SEPARATOR 0: Comma, 1: Semicolon, 2: Tab
DECIMAL POINT 0: Period, 1: Comma
DATE FORMAT 0: YYYY/MM/DD
1: DD/MM/YYYY
2: MM/DD/YYYY
Range Measurement range, source range
0% VALUE
100% VALUE
CONTACT (contact I/O)
TC SETTING
(temperature setting)
0: OFF, 1:ON
Thermocouple terminal setting. 0: TC-A, 1: TC-B
TC-B RJC setting. 0: OFF, 1:ON
Burnout setting. 0: OFF, 1:ON
TC scale standard setting. 0: ITS-90, 1:IPTS-68
FREQUENCY SETTING
(frequency setting)
Temperature unit. 0: °C
Pulse count setting
MODEL NO. Model number
TAG NO. Tag number
SERIAL NO. Serial number
CALIBRATION DATE Calibration date
YYYY/MM/DD
CALIBRATOR S/N CA550 serial number
No. Calibration point number
DATE Calibration date YYYY/MM/DD
TIME Calibration time of the calibration point hh:mm:ss
MEASURE Measurement value
SOURCE Source value
ERROR% Error
PASS/FAIL Pass/fail
Errors and Pass/Fail Judgment
The instrument determines the error in the actual output value of the measured calibration target
relative to the output value (specified according to the specifications of the device to be calibrated)
that is mapped to the source value and saves it as a percentage.
The instrument judges pass or fail depending on whether the value is within the tolerance specified
in the SETUP menu of Function 1.
Proper judgment cannot be made unless the 0% or 100% measurement value of this instrument is
assigned to the output value (specified according to the specification of the device to be calibrated)
that is mapped to the 0% or 100% source value of this instrument.
5.2 Saving Sweeps
