Saving Data
CA550
For a step sweep, the same information as that explained in “Saving Data Manually” in Section 5.1
is saved in a single CSV file. If you abort a sweep, the data up to that point is saved.
For a program sweep, the same information as that explained in “Saving Data Manually” in Section
5.1 and the calibration target information are saved in a single CSV file. If you abort a sweep, the
data is not saved.
A total of up to 250 step sweep and program sweep files can be saved.
File Name
The following file name is automatically assigned.
Step sweep: YYYYMMDDhhmmss_xx.csv
YYYYMMDDhhmmss: year, month, day, hour, minute, and second
when the data entry was saved
YYYY: year, MM: month, DD: day, hh: hour, mm: minute, ss: second
xx: A sequence number starting from 00 that is assigned when the
save date and time overlaps
Program sweep: Tag No. + YYYYMMDDhhmm_xx.csv
YYYYMMDDhhmm: year, month, day, hour, and minute when the data
entry was saved
xx: A sequence number starting from 00 that is assigned when the
save date and time overlaps
Saved Information
The following information is saved.
Saving Data Using Step Sweep
Saved data Notes
MODEL CA550
FILE TYPE 0: Manually saved data using the SAVE key
1: Automatically saved data by a step sweep
2: Calibration data by a program sweep
CSV SEPARATOR 0: Comma, 1: Semicolon, 2: Tab
DECIMAL POINT 0: Period, 1: Comma
DATE FORMAT 0: YYYY/MM/DD
1: DD/MM/YYYY
2: MM/DD/YYYY
Range Measurement range, source range
0% VALUE
100% VALUE
DIVISION NUMBER (number of divisions)
CONTACT (contact I/O) 0: OFF, 1:ON
TC SETTING
(temperature setting)
Thermocouple terminal setting. 0: TC-A, 1: TC-B
TC-B RJC setting. 0: OFF, 1:ON
Burnout setting. 0: OFF, 1:ON
TC scale standard setting. 0: ITS-90, 1:IPTS-68
Temperature unit. 0: °C
FREQUENCY SETTING
(frequency setting)
Amplitude voltage setting
Pulse count setting
No. Number
DATE Measurement date YYYY/MM/DD
TIME Measurement time hh:mm:ss
MEASURE Measurement value
SOURCE Source value
5.2 Saving Sweeps
