5.5 Saved Data Format (CA550)
The saved data (CSV) format on the CA550 is as follows:
Data Saved Using the SAVE Key
MODEL CA550
FILE TYPE 0
CSV SEPARATOR 0
DECIMAL POIINT 1
DATE FORMAT 0
RANGE 4-20mA Type-K
0%VALUE 4 0
100%VALUE 20 100
CONTACT 0 0
TC SETTING 0 0 1 0
FREQUENCY SETTING 1.0 0
No. DATE TIME FUNCTION2 FUNCTION1
1 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
2 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
3 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
4 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
Function1 settings
Function2 settings
Measurement/source
value
Data Saved Using Step Sweep
MODEL CA550
FILE TYPE 2
CSV SEPARATOR 0
DECIMAL POIINT 1
DATE FORMAT 0
RANGE 4-20mA Type-K
0%VALUE 4 0
100%VALUE 20 100
CONTACT 0 0
TC SETTING 0 0 1 0
FREQUENCY SETTING 1.0 0
No. DATE TIME FUNCTION2 FUNCTION1
1 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
2 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
3 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
4 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
5 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
6 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
7 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
8 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
9 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
10 xxxx/xx/xx xx:xx:xx ±xxx.xx ±xx.xxx
