To change the channel:
[ 1 Displaying the window
F
2
Press the F2 key.
The window for selecting the channel appears.
(The display differs depending on the setting of wiring.)
Example of wiring: 1P3W
P
I2
I1
U2
U1
[ 2 Selection
Using the cursor key, select CH to be displayed (highlighted).
If you do not change the setting, press the ESC key. The window returns to
the List screen.
[ 3 Confirmation
ENTER
Press the ENTER key.
This closes the window, returning you to the List screen.
Display of the Window According to Wiring Setting
Wiring
Elements
U1
I1
P
U1
U2
I1
I2
P
U1
U2
I1
I2
I4
P
U1
U2
U3
I1
I2
I3
P
U1
U2
U3
I1
I2
I3
I4
P
U1_3P
U2_3P
U3_3P
U1_1P
U2_1P
I1_3P
I2_3P
I3_3P
I1_1P
I2_1P
P_3P
P_1P
1P2W 1P3W 1P3W3I
3P3W2I
3P3W3I
3P4W
3P4W4I 3P3W+1P3W
For multiple loads, A number representing load(s) is appended following element.
Example: LOAD1 I1_1
LOAD2 I1_2
