17-13
IM CW240E
CW 240 Specifications
17
● Connection Confirmation (Wiring Check) Function
Confirms voltage/current input values, voltage/current phase difference,
voltage-to-voltage phase difference, current-to-current phase difference,
suitability of frequency measurement.
For Scott connections, confirms single-phase load connection.
Wiring diagram, vector diagram display
● Setting Confirmation (Setting Check) Screen
Screen for confirming integration measurement data save items, start/end, etc.
● Other Functions
VT ratio/CT ratio setting, ID number setting, NiMH (nickel metal hydride) battery
charge, battery residual quantity display, beep (key operation confirmation), key
lock, system reset
(5) Communication Function
Electrical Specifications E1A RS-232
Synchronization Method Start/stop synchronization
Baud Rate 1200/2400/9600/19200/38400 bps
Connectors D-SUB 9 pin
(6) PC Card Interface
Slot "PC Card Standard" conforming TYPE II ⫻ 1 set
Usable Cards Flash ATA card
Data Format MS-DOS format
Storage Content Setting data, measurement data, screen
data
(7) External Control Input/Output
Integration measurement start/end control input/output
Control Input TTL level or contact point
Control Output TTL level
17.1 CW 240 Specifications
